Key Features:
1）Long cycle life: More than 2000 times (charging and discharging at 1C,remain capacity more than 80%)
2) It operates 72V high voltage
3）Safety: No fire and explosion in overcharge test at voltage up to 30V in short-circuit test, Acupuncture test and heat shock up to 130℃
3）Safety: No fire and explosion in overcharge test at voltage up to 30V in short-circuit test, Acupuncture test and heat shock up to 130℃
4）Excellent high temperature performance: operate in 85℃ could working well.
5) Lntelligent BMS Battery Management system.
6) Environmental friendly.
| Model |
Nominal Voltage |
Nominal Capacity (Ah) |
Internal Resistance (mΩ) |
Life Cycles |
Maximum Charge Voltage |
Cut-off Discharge Voltage |
Continuous Discharge Current |
Battery weight (Approx.) |
Measurement (T*W*L) |
| FT-23L10 | 72V | 10Ah | ＜200 | ≥2000 | 84.0V | 52.9V | 10A | 15.0Kg |
185*165*190mm or |
| FT-23L20 | 72V | 20Ah | ＜200 | ≥2000 | 84.0V | 52.9V | 20A | 23.0kg | Customized |
| FT-23L30 | 72V | 30Ah | ＜200 | ≥2000 | 84.0V | 52.9V | 30A | 27.0kg | Customized |
| FT-23L40 | 72V | 40Ah | ＜200 | ≥2000 | 84.0V | 52.9V | 40A | 34.0kg | Customized |
| FT-23L50 | 72V | 50Ah | ＜200 | ≥2000 | 84.0V | 52.9V | 50A | 45.0kg | Customized |
| Custom model | 72V | / | / | ≥2000 | 84.0V | 52.9V | / | / | Customized |
