Key Features：
1）Long cycle life: More than 2000 times (charging and discharging at 1C,remain capacity more than 80%)
2) Flexible design: capacity range from 10Ah to 1000Ah.
2) Flexible design: capacity range from 10Ah to 1000Ah.
3）Safety: No fire and explosion in overcharge test at voltage up to 30V in short-circuit test, Acupuncture test and heat shock up to 130℃
4）Excellent high temperature performance: operate in 85℃ could working well
5) Lntelligent BMS Battery Management system.
6) Environmental friendly.
| Model |
Nominal Voltage |
Nominal Capacity (Ah) |
Internal Resistance (mΩ) |
Life Cycles |
Maximum Charge Voltage |
Cut-off Discharge Voltage |
Continuous Discharge Current |
Battery (Approx.) |
Measurement(T*W*L) |
FT-4L10 |
12V | 10Ah | ≤60 | ≥2000 | 14.6V | 9.2V | 10A | 1.5Kg | 151*98*95mm or Customized |
FT-4L20 |
12V | 20Ah | ≤30 | ≥2000 | 14.6V | 9.2V | 20A | 2.8Kg | 181*76*166mm or Customized |
| FT-4L30 | 12V | 30Ah | ≤30 | ≥2000 | 14.6V | 9.2V | 30A | 3.8Kg |
|
| FT-4L40 | 12V | 40Ah | ≤10 | ≥2000 | 14.6V | 9.2V | 40A | 5.7Kg | 182*130*195mm or Customized |
| FT-4L50 | 12V | 50Ah | ≤8 | ≥2000 | 14.6V | 9.2V | 50A | 6.0Kg | 182*130*195mm or Customized |
| FT-4L60 | 12V | 60Ah | ≤8 | ≥2000 | 14.6V | 9.2V | 60A | 8.0Kg | 228*137*216mm or Customized |
| FT-4L80 | 12V | 80Ah | ≤5 | ≥2000 | 14.6V | 9.2V | 80A | 12Kg | 318*181*168mm or Customized |
| FT-4L100 | 12V | 100Ah | ≤5 | ≥2000 | 14.6V | 9.2V | 100A | 13.5Kg | 305*173*225mm or Customized |
| FT-4L150 | 12V | 150Ah | ≤4 | ≥2000 | 14.6V | 9.2V | 100A | 20.6Kg | 295*178*345mm or Customized |
| FT-4L200 | 12V | 200Ah | ≤4 | ≥2000 | 14.6V | 9.2V | 100A | 28.1Kg |
|
| FT-4L250 | 12V | 250Ah | ≤4 | ≥2000 | 14.6V | 9.2V | 100A | 35.0kg | 520* 269*203mm or Customized |
| FT-4L300 | 12V | 300Ah | ≤4 | ≥2000 | 14.6V | 9.2V | 100A | 42.0kg | . Customized . |
| Custom model | 12V | / | / | ≥2000 | 14.6V | 9.2V | / | / | . Customized . |
